Home > Product > Hydraulic Hose > SAE 100R2AT/DIN 2SN
SAE 100R2AT/DIN 2SN
Model :
Category : Hydraulic Hose
Product Name : SAE 100R2AT/DIN 2SN

Product Details :
Wire Braid Hydraulic Hose:
SAE 100 R2AT/DIN EN 853 2SN STANDARD
Tube :
Oil resistant synthetic rubber
Reinforcement :
one high tensile steel wire braid
Cover :
Abrasion and weather resistant synthetic rubber
Temperature range :
-40 ℃ to +100 ℃
DN Hose I.D Hose O.D Working Pressure Burst Pressure Min. Bend Radius Weight Length
　 inch mm mm MPa psi MPa psi mm kg/m metres
5 3/16" 4.8 13.4 41.4 6000 165 23720 89 0.32 50/100
6 1/4" 6.4 15 40 5800 160 22840 102 0.36 50/100
8 5/16" 7.9 16.6 36 5250 140 20000 114 0.45 50/100
10 3/8" 9.5 19 33.1 4800 132 18840 127 0.54 50/100
13 1/2" 12.7 22.2 27.6 4000 110 15720 178 0.68 50/100
16 5/8" 15.9 25.4 25 3630 100 14280 203 0.8 50/100
19 3/4" 19 29.3 21.5 3120 85 12280 241 0.94 50/100
25 1" 25.4 38 16.5 2400 65 9420 305 1.35 50
32 1 1/4" 31.8 48.3 12.5 1820 50 7140 419 2.15 20/40
38 1 1/2" 38.1 54.6 9 1310 36 5140 508 2.65 20/40
51 2" 50.8 67.3 8 1160 32 4560 635 3.42 20/40
